Name: Titan Heavy-Duty Manual Wheelchair - 560mm
Brand: Cubro
SKU: WEEL-TITAN-MANUAL-56-BOX7
Price: 1494.95 NZD
Availability: InStock

Titan Heavy-Duty Manual Wheelchair - 510mm

Titan Heavy-Duty Manual Wheelchair - 560mm

$1,494.95 - $1,494.95

$1,494.95

$1,494.95 - $1,494.95

$1,494.95

Quantity

SuperGold Card accepted here A registered SuperGold business partner

Not sure this is the right wheelchair? Compare wheelchairs side by side

Bariatric strength, backed by a 5-year warranty — rated to 204kg. The Titan is a heavy-duty self-propelled wheelchair built from reinforced heavier-gauge steel, with a wide 560mm seat and double-thickness upholstery. Solid puncture-proof tyres, removable arms and swing-away footrests — supplied and supported by Cubro NZ.

WILL IT FIT?
✔ Extra-wide 56cm seat, rated to 204kg — built for larger users
✔ Wide 76cm overall — check your doorways (needs roughly 78cm clear)
✔ Self-propel — large rear wheels with hand rims; a carer can also push
✔ Sturdy 24kg steel frame — folds to 30cm; best as a two-person lift or kept where it's used
✔ Double-thickness vinyl upholstery for comfort and durability
✔ Removable arms, swing-away footrests and solid puncture-proof tyres

💰 May be funded by WINZ, ACC, Enable or Accessable
Many Kiwis get help with the cost of their mobility equipment. See how funding works — or just ask us.

📄 Request a written quote or a callback For WINZ, ACC, Enable, Accessable or your OT — or if you’d rather we phoned you

Big decision? Talk to a real person — 100% Kiwi whānau business since 2005.

Shipping Costs & Delivery Time

North Island: $16.95
South Island: $29.95
Express North Island: $26.95
Express South Island: $39.95
Fast-Tracked NZ Delivery - Daily Dispatch

North Island: 1-2 Working Days
South Island: 3-4 Working Days
Rural Deliveries: Please Allow An Extra 2-3 Working Days

Full delivery & shipping info

12-Month NZ Warranty & 30-Day Returns

Minimum 12-Month NZ-Backed Warranty On All Products.
30-Day Hassle-Free Returns On Many Products.

Kia ora

Hi, I'm Kellie — I own Mobility Plus and personally look after every order. Not sure which product is right for you or your whānau? Browse our buying guides or call me on 0220229956 before you buy.

Everything You Need to Know About This Product...

Description

Built tough, warranted for 5 years

When capacity and durability matter most, the Titan delivers: a reinforced heavier-gauge steel frame rated to 204kg, a wide 560mm seat and double-thickness vinyl upholstery for comfort and long life. It self-propels or a carer can push, and it's backed by a 5-year warranty through Cubro NZ — far beyond a typical budget chair.

• Heavy-duty reinforced steel frame, 204kg rated
• Wide 560mm (56cm) seat
• Self-propelled with large rear wheels and hand rims
• Solid puncture-proof tyres
• Removable arms and swing-away footrests
• Double-thickness upholstery
• Other seat widths available on request
• 5-year warranty
• Supplied by Cubro NZ

Product Specifications

SPECIFICATIONS
Type: Heavy-duty / bariatric self-propelled
Seat width: 56cm (560mm)
Seat depth: 51cm (510mm)
Seat height: 51cm (510mm)
Backrest height: 45cm (450mm)
Armrest height: 22.5cm (225mm)
Overall width: 76cm (760mm)
Overall length: 112cm (1120mm)
Overall height: 91cm (910mm)
Folded (closed) width: 30cm (300mm)
Chair weight: 24kg
Max user weight: 204kg
Frame: Heavier-gauge steel, reinforced, double-cross brace
Tyres: Solid (puncture-proof)
Arms: Removable
Footrests: Swing-away, detachable
Upholstery: Double-thickness vinyl
Warranty: 5-year · Supplied by Cubro NZ

Instructions & Downloads

Download instructions here

FAQs - Your Questions Answered

Why is this more than a cheap online chair?
The Titan is built from reinforced heavier-gauge steel, rated to 204kg, and backed by a 5-year warranty with parts and servicing through Cubro NZ. A budget chair rarely offers this strength, capacity or after-sales support.

Who is the Titan for?
Larger users who need a strong, supportive wheelchair. It's a bariatric chair rated to 204kg with a wide 560mm seat.

Can it be self-propelled?
Yes — it has large rear wheels with hand rims so the user can push themselves, and it can also be pushed by a carer.

What makes it heavy-duty?
It's built from heavier-gauge steel tubing, reinforced in high-stress areas, with double-cross brace arms for extra strength.

Are the arms and footrests removable?
Yes — the arms are removable and the footrests swing away and detach, making transfers easier.

Do the tyres need pumping up?
No — it has solid puncture-proof tyres, so there's no maintenance and no flats.

Does it come in other sizes?
This is the 560mm seat model. Other seat widths are available on request — get in touch.

What warranty is included?
A 5-year warranty, supplied and supported by Cubro NZ.

Who supplies this?
Cubro NZ.

Will this wheelchair fit? Measure first — it takes two minutes

Seat width is the single most common reason a wheelchair gets sent back. Too narrow and it rubs and hurts; too wide and the user slumps sideways and can’t reach the wheels properly. Grab a tape measure and check these four numbers before you order.

Not to scale — use it to find the four measurements, not to judge proportions.

A
Seat width
Sit the user on a firm chair, knees together. Measure straight across the widest point of the hips or thighs. Then add 2–4cm. That total is the seat width to order — the extra allows for winter layers without letting them slide about.
B
Seat depth
Sitting, measure from the back of the bottom to the back of the knee. Take 5cm off. A seat that runs right to the knee presses on the back of the leg and cuts circulation.
C
Floor to seat height
Measure from the heel to the back of the knee with shoes on. The footplates need to sit at that height with thighs level. If the user will push themselves along with their feet, you want a lower seat so both heels reach the floor.
D
Backrest height
For a self-propelled chair, the back should finish just below the shoulder blades so the arms swing freely. For a transit chair pushed by someone else, a higher back gives more support.

Quick check: how wide are the hips, sitting down? (cm)

Print the measuring sheet

Still not sure? Ring Kellie on 022 022 9956 or send us the measurements and we’ll tell you honestly which chair to buy — or that none of ours is right. This is a general guide, not a clinical assessment: if the user has pressure areas, a spinal condition or sits asymmetrically, please get an occupational therapist involved.
